Cisco HyperFlex HX240c-AF-M5
Cisco HyperFlex HX240c AF M5 All Flash Node
More pricing below, click here!
Please Note: All Prices are Inclusive of GST
Overview:
Mobility, big data, and the Internet of Everything (IoE) are changing application architectures and IT delivery models. Keeping pace requires a systems-centric strategy in your data center. Cisco HyperFlex™ systems deliver adaptability with complete hyperconvergence. These innovative systems combine software-defined networking and computing with the next-generation Cisco HyperFlex HX Data Platform. Engineered on the Cisco Unified Computing System™ (Cisco UCS®), Cisco HyperFlex systems deliver pay-as-you-grow economics and extend model-based management to the cloud.
Features:
Independent scaling
The HX Data Platform is designed for independent scaling of compute, caching, and capacity, giving you full flexibility to scale your hyperconverged environment based on evolving business needs.
Multiple hypervisors
Extensible file system supporting multiple hypervisor choice without compromising performance.
Multicloud services
Enable any application tier to be deployed, monitored, and managed anywhere.
Flash optimized
The log structured file system writes to SSDs sequentially, reducing flash wear while delivering blazing fast performance at low latency.
Stretch clusters
A single cluster with nodes distributed across sites for mission-critical workloads and high availability across geographies.
Dynamic data optimization
Incoming data is distributed and optimized across nodes as well as storage tiers with inline deduplication and compression, eliminating performance bottlenecks and achieving high IO performance.
Simplified data management
Dramatically simplify daily operations of your hyperconverged infrastructure. Integrated data management functionality for applications includes instant provisioning, cloning, snapshots, replication for disaster recovery protection, and data-at-rest encryption.
Product Specifications:
Models Comparison:
Designed to provide high availability, security, investment protection, high quality of service, energy efficiency, and ease of operation, these switches are ideally suited to support demanding applications such as IP telephony, wireless, and video.
The tables below provide high-level comparisons of the different models available in the HyperFlex HX-Series. You may view all models with:
- With LAN Base Software
- With IP Base Software
All models support network modules with four 1G SFP, two 10G SFP+, or two 10GBase-T uplink ports.
The IP Services feature set is available as an upgrade option at the time of ordering or through a license at a later time. A 440W DC power supply is available as a configurable option on all the switch models.
| Cisco HyperFlex HX-Series Switches with LAN Base Software | |||||
|---|---|---|---|---|---|
| Model | HX240c-AF-M5-24T-L | HX240c-AF-M5-48T-L | HX240c-AF-M5-24P-L | HX240c-AF-M5-48P-L | HX240c-AF-M5-48PF-L |
| Total 10/100/1000 Ethernet Ports | 24 | 48 | 24 POE+ | 48 POE+ | 48 POE+ |
| Uplinks | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G |
| Default AC Power Supply Rating with Dual Modular Slots | 350W | 350W | 715W | 715W | 1100W |
| Default POE Power | - | - | 370W | 370W | 740W |
| Cisco HyperFlex HX-Series Switches with IP Base Software | |||||
| Model | HX240c-AF-M5-24T-S | HX240c-AF-M5-48T-S | HX240c-AF-M5-24P-S | HX240c-AF-M5-48P-S24T-L | HX240c-AF-M5-48PF-S24T-L |
| Total 10/100/1000 Ethernet Ports | 24 | 48 | 24 POE+ | 48 POE+ | 48 POE+ |
| Uplinks | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G | Modular 4x1G, 2x10G |
| Default AC Power Supply Rating with Dual Modular Slots | 350W | 350W | 715W | 715W | 1100W |
| Default POE Power | - | - | 370W | 370W | 740W |
Documentation:
Download the Cisco HyperFlex HX240c Datasheet (PDF).
